Laboratory facility
Mechanical Department is equipped with state of art, ultra-modern and sophisticated lab instruments.
The department has following laboratories:
ELEMENTS OF MECHANICAL ENGINEERING
- Model of lancashire boiler
- Model of cochran boiler
- Model of babcoke&wilcox boiler
- Model of locomotive boiler
- Model of cornish boiler
- Green economiser
- Tubewell model
- Petrol engine 2 stroke
- Petrol engine 4 stroke
- Diesel engine 2 stroke
- Diesel engine 4 stroke
- Sudgen superheater
- Pendulum pump
- Water pump
- Reciprocating pump
- Gear pump
- Centrifugal pump
- Rotary pump
- Air lift pump
- Deep well turbine pump
ENGINEERING GRAPHICS
- Set Square
- Protector
- Divider
- Scale
- Models of Solids
MECHANICS OF SOLIDS
- Rockwell cum brinell hardness testing machine
- Izod impact testing machine
- Universal testing machine – electronic – 20 tone
- Universal force table
- Beam reaction apparatus
- Bridge trusses – lattice bowstring type
- Bell crank lever , ( on angle iron base with weights)
- Combined inclined plane & friction slide apparatus - with angle iron base with weights
MATERIAL SCIENCE AND METALLURGY
- Ultrasonic flaw detector
- Magnetic particle testing machine yoke type
- Dye penetrate test kit
- Microscope-inverted metallurgical
- Dry belt surface (single belt)
- Single disc polishing machine - variable speed
- Jomney end quench apparatus -with furnace
- Microscopic specimen- metallurgical set of 23
MECHANICAL MEASUREMENT AND METROLOGY
- Venier Caliper
- Micrometer (Outside micrometer)
- Micrometer (Inside micrometer)
- Micrometer (Depth micrometer)
- Vernier Depth Gauge
- Vernier Height Gauge
- Combination Square
- Bevel Protector
- Sine Bar
- Clinometer (Vernier/Micrometer)
- Surface Plate
- Slip Gauge (calibration (AA))
- Dial bore Gauge
- Autocolimeter (Straightness & flatness/small angular)
- Plug Gauge
- Plain Ring Gauge
- Dial Snap Gauge
- Spirit level
- Angle Dekkor
- Thermocouples
- Resistance Temperature Detectors
- Thermistor
- Bimetallic Strip/ Thermometer
- Pressure Thermometer
- Hydraulic Load Cell
- Proving Ring
- Feeler Gauge
- Screw Thread / Pitch Micrometer
- Disc Micrometer
- Gear Tooth Vernier Caliper
- Dial Gauge with Magnet Stand (Comparator)
- Non-Contact Infrared Thermometer
FLUID MECHANICS
- Pressure measurement apparatus
- Bernoulli`s theorem apparatus
- Reynold`s apparatus
- Pipe friction loss apparatus (major loss)
- Metacentric height apparatus setup
- Pipe fittings loss apparatus (minor loss)
- Notch apparatus
- Venturimeter & Orificemeter apparatus
- Flow measuring apparatus
- Pitot static tube apparatus
- Viscometer
- Electric pressure transducer
- centre of pressure apparatus
WORKSHOP
- Smithy shop
- Carpentry shop
- Plumbing shop
- Sheet metal shop
- Fitting shop
- Foundry shop
- Lathe machine
- Drilling machine
- Grinding machine
- Shaper machine
- Milling machine
- Arc welding machine
- Resistance welding machine
- MIG welding machine
- TIG welding machine
- Furnace with electric blower
- Lathe Tool Dynamometer
- Press Tool
- JIG and Fixture
DYNAMICS OF MACHINERY LAB
- Static and Dynamic Balancing Apparatus
- Universal Vibration Apparatus
- Whirling of shaft
- Cam Analysis Apparatus
KOM & TOM LAB
- Internal expansion break
- Epicyclic gear train
- Two stage spur gear
- Conical friction clutch
- Belt pulley
- Shafting bearing
- Ball and Roller bearing
- Ball and taper bearing
- Ball and thrust bearing
- Swivel bearing
- Rack and quadrant gear
- Different types of brake
- Different types of clutch
- Pulley demonstration set
- Sliding wedge gear with straight line
- Single stage bevel gear
- Single stage spiral gear
- Herringbone gear
- Gear set - Set of 4
- Inter connected gear
- Single stage spur gear
- Rack & pinion
- Cycloidal gear
- Worm gear
- Reversing gear
- Plate clutch
- Belt drive single speed
- Belt drive double speed
- Internal gear pinion drive
- Gear box forward & reverse
- Gyroscope
- Governer
REFRIGERATION AND AIR CONDITIONING LAB
- Refrigeration test rig
- Absorption refrigeration system
- Window air cooler test rig
- Air conditioning test rig
- Various tools for refrigeration for tubing(Flaring, Swaging, Bending and Brazing)
- Heat pump test rig
- Refrigeration charts
IC Engine Lab
- MEASUREMENT OF CALORIFIC VALUE FOR SOLID/LIQUID/GASEOUS FUEL
-
CUT SECTION MODELS OF VARIOUS CARBURETORS
1.SOLEX
2.MARUTI - MODEL OF ENGINE COOLING SYSTEM
- MODEL OF ENGINE LUBRICATING SYSTEM
FLUID POWER ENGINEERING LAB
- Test rig of Pelton turbine
- Test rig of Kaplan turbine
- Test rig of Francis turbine
- Test rig of Centrifugal pump
- Test rig of Reciprocating pump
- Test rig of Centrifugal compressor
- Test rig of Reciprocating compressor
- Impact of jet apparatus
- Test rig of Hydraulic ram
HEAT AND MASS TRANSFER LAB
- Apparatus to determine thermal conductivity of metal rod
- Hea Transfer co-efficient For Transient Heat Transfer Appratus
- Composite wall apparatus
- Filmwise Condensation appratus
- Pin fin apparatus
- Emissivity measurement apparatus
- Stefan Boltzmann apparatus
- Critical radius apparatus
